air
cooled type industrial water chiller |
|
|
| |
|
|
|
|
model
|
RP-1/2
|
RP-1 |
RP-2 |
RP-3 |
RP-5 |
RP-8 |
RP-10 |
RP-12 |
|
refrigerated
capacity
|
kcal/h |
1220 |
2400 |
4900 |
7500 |
13500 |
21600 |
27000 |
30800 |
| KW |
1.4 |
2.7 |
5.7 |
8.7 |
15.6 |
25.1 |
31.4 |
35.8 |
| USRT |
0.4 |
0.8 |
1.6 |
2.4 |
4.4 |
7.1 |
8.9 |
10.2 |
|
can
control temp
°C |
+
3°C
- + 40°C |
|
power
source
|
1Ø
220V 50HZ
|
3Ø
380V 50HZ(can select 60HZ) |
|
compressor
power kw |
0.37 |
0.75 |
1.5 |
2.25 |
3.75 |
6 |
7.5 |
9 |
|
refrigerant |
R-22（can
select R407C/R134a/R404A/R410A) |
|
in/out
pipe inch |
1(1/2) |
1(1/2) |
1 |
1 |
1 |
1-1/2 |
1-1/2 |
1-1/2 |
|
condenser
|
type |
cross-finned
tubes |
| air
m3/min |
18 |
18 |
50 |
50 |
120 |
240 |
240 |
240 |
|
water
tank
evaporator
|
volume
L
|
20 |
20 |
32 |
40 |
74 |
132 |
132 |
132 |
| （can
select shell pipe evaporator） |
| standard ice
water L/min |
5-80 |
10-80 |
20-80 |
30-100 |
50-100 |
80-120 |
100-160 |
120-160 |
|
ice
water pump kw |
0.37 |
0.37 |
0.37 |
0.37 |
0.37 |
0.75 |
0.75 |
0.75 |
| protection
device |
time
delay,the protection of water
shortage,the control and display of
high and low pressure,the control and
display of temperature,the
protectionof over load,the oil
heating,the errors display and so on.
|
|
outside
dimensions
|
H mm |
790 |
830 |
850 |
1120 |
1265 |
1270 |
1250 |
1625 |
|
W mm |
392 |
420 |
430 |
510 |
550 |
660 |
565 |
710 |
|
D mm |
646 |
646 |
755 |
825 |
905 |
1200 |
1525 |
1950 |
|
| |
|
model
|
RP-15
|
RP-20 |
RP-25 |
RP-30 |
RP-40 |
RP-50 |
RP-60 |
RP-80 |
|
refrigerated
capacity
|
kcal/h |
3600 |
52200 |
63500 |
71200 |
97800 |
129400 |
154500 |
209900 |
| KW |
41.8 |
60.6 |
73.8 |
82.7 |
113.7 |
150.4 |
179.6 |
244.1 |
| USRT |
11.9 |
17.3 |
21 |
23.5 |
32.3 |
42.8 |
51.1 |
69.4 |
| can
control temp
°C |
+
3°C
- + 40°C |
|
power
source
|
3Ø
380V 50HZ(can
select 60HZ) |
| compressor
power
kw |
11.25 |
15 |
18.75 |
22.2 |
30 |
37.5 |
45 |
60 |
| refrigerant |
R-22（can
select R407C/R134a/R404A) |
| in/out
pipe inch |
2 |
2 |
2-1/2 |
2-1/2 |
3 |
3 |
3 |
4 |
| condenser |
type |
cross-finned
tubes |
| air
m3/min |
360 |
360 |
560 |
560 |
720 |
900 |
1160 |
1460 |
| evaporator |
water
tank volume L |
200 |
370 |
370 |
450 |
500 |
shell
pipe(can select water tank
evaporator)
|
| （can
select shell pipe evaporator） |
| standard ice
water L/min |
150-250 |
200-250 |
250-350 |
300-350 |
400-560 |
500 |
571 |
747 |
| ice
water pump kw |
1.5 |
1.5 |
2.2 |
2.2 |
3.75 |
3.75 |
5.6 |
7.5 |
|
protection
device |
time
delay,the protection of water
shortage,the control and display of
high and low pressure,the control and
display of temperature,the
protectionof over load,the oil
heating,the errors display and so on.
|
|
outside
dimensions
|
H mm |
1625 |
1650 |
1750 |
1880 |
1880 |
1905 |
2350 |
2500 |
| W mm |
710 |
1350 |
1020 |
1360 |
1700 |
1732 |
2000 |
2200 |
| D mm |
1950 |
1560 |
1700 |
2100 |
2100 |
2195 |
3000 |
4350 |
|
| |
|
model
|
RP-100
|
RP-120 |
RP-160 |
RP-180 |
RP-200 |
RP-240 |
|
refrigerated
capacigy
|
kcal/h |
269300 |
314900 |
430500 |
480100 |
538100 |
629900 |
| KW |
313.1 |
366.2 |
500.6 |
558.3 |
625.7 |
732.4 |
| USRT |
89.1 |
104.1 |
142.4 |
158.8 |
177.9 |
208.3 |
| can
control temp
°C |
3°C
- + 40°C |
|
power
source
|
3Ø
380V 50HZ(can
select 60HZ) |
| compressor
power
kw |
75 |
90 |
120 |
135 |
150 |
180 |
| refrigerant |
R-22（can
select R407C/R134A/R404A) |
| in/out
pipe inch |
4 |
4 |
5 |
5 |
6 |
6 |
| condenser |
type |
cross-finned
tubes |
| air
m3/min |
1920 |
2385 |
2900 |
3360 |
3830 |
4780 |
| evaporator |
type |
shell
pipe |
| standard ice
water L/min |
933 |
1162 |
1496 |
1714 |
1934 |
2326 |
|
protection
device |
time
delay,the protection of water
shortage,the control and display of
high and low pressure,the control and
display of temperature,the
protectionof over load,the oil
heating,the errors display and so on.
|
|
outside
dimensions
|
H mm |
2500 |
2500 |
2800 |
2800 |
2800 |
3000 |
| W mm |
2200 |
2200 |
2500 |
2500 |
2500 |
2500 |
| D mm |
4350 |
4500 |
6000 |
6000 |
6000 |
7500 |
|
|
the cooling based on the following condtions：
1. ice water in/out temp：12/7℃
2. ambient temp：30℃ |
|
other
specification according to demand.
-
reserves
the right to modify the details shown here in
without prior notification. |
| |
|
|
|
